5"×1.25" TPR thermoplastic rubber wheel - Swivel top caster with side brake top locking - 325lbs capacity | 330PS-125032ANB-92GF-STA

Part No.: 330PS-125032ANB-92GF-STA
Wheel Dia.: 126mm / 5inch caster

Tread Width: 32mm / 1.25inch caster
Wheel Type: Grey TRP wheel

Caster Type: Side brake swivel caster
Fitting Type: Top plate caster

Load Cap.: 147kg / 325 lbs caster
APP: Light-Medium duty casters

Order Technical Support

*　Product Name：	Please enter the product name ordered
*　Name：	Please enter your name
*　Tel：	Please enter your phone
*　Email：	Please enter your correct email address
*　Order message：	Please enter your order message
	Yes, I'd like to receive news about 5"×1.25" TPR thermoplastic rubber wheel - Swivel top caster with side brake top locking - 325lbs capacity \| 330PS-125032ANB-92GF-STA.

Details

Technical Data

CASTER TECHNICAL	°C / mm / kg	°F / inch / lbs
Wheel Diameter (D)	126 mm	5 inch
Width of Tread (W)	32 mm	1.25 inch
Wheel Material	Grey TPR on PP core wheel
Hardness of Tread	65 to 75+/-5 Shore A
Wheel Bearing	Annular ball bearing
Caster Brake	Side brake swivel caster, top lock wheel face
Fitting Type	Top plate
Plate Size (A×B)	93×63 mm	3.63×2.5 inch
Hole Centers (X×Y - X'×Y')	78×45 - 70 mm	3.06×1.75 - 2.79 inch
Plate Hole (P)	8.2 mm	0.32 inch
Swivel Offset (E)	32 mm	1.26 inch
Swivel Radius (R)	96 mm	3.81 inch
Load Height (H)	156mm	6.18 inch
Load Capacity	147 kg	325 lbs
Caster Weight	1.2 kg	2.7 lbs
Packing	30PCS/CTN
Remark	ROHS
Part Number	330PS-125032ANB-92GF-STA
SKU	6912503003

Features

5"×1.25" TPR Wheel Swivel Top Caster with Side Brake

330 Series performance TPR (Thermoplastic Rubber) or TPE (Thermal Plastic Elastomer) wheel caster is specially engineered to provide unsurpassed durability and reliability. Non-marking thermoplastic elastomer flat tread is permanently bonded to a ribbed polyolefin wheel core. WandaTool TPR wheel offers the advantages of both hard and soft tread materials in a single wheel. Like a hard tread wheel, TPR wheel rolls easily and is very durable. Like a soft tread wheel, it rolls quietly, protects floors and resists impacts with a cushion ride. Absorbs shock to help protect equipment.
